CNC-Horizontal-Machining Centre HÜLLER HILLE Nb-h 170 Speed
Details
| Make: | HÜLLER HILLE |
| Type: | Nb-h 170 Speed |
| Built: | 2004 |
| Control: | SINUMERIK 840 D |
Description
The horizontal machining center Hüller Hille nbh-170 speed is equipped with a Siemens SINUMERIK 840D control.
This BAZ with increased rapid traverse speed has a double pallet changer in pallet size of 500x630mm and a full NC rotary table with pitch 360 x 0.001°.
The main spindle in size HSK100 with internal coolant supply and drive power 50kW as well as the large tool magazine with 150 places complete the performance package of this machine.
Technical Equipment & Features
- Power spindle size HSK 100
- Main spindle 50 kW, 12.000 min-1
- IKZ
- NC-rotary table 360x0,001°
- Rapid traverse in linear axes 50m/min
- 150-fold ATC in 3 magazine cassettes HSK 100
- 2-fold pallet changer with in total 4 piece pallets 630 x 500 mm
- 3D-measuring probe RENISHAW OMP 60
- 2 piece chip conveyors longitudinal
- Coolant equipment with paper band filter, internal coolant
- BRANKAMP tool monitoring
- Exhaust ELBARON
