used CNC Gear Shaping Machine LORENZ LS 82
| manufacturer: | LORENZ |
| type: | LS 82 |
| built: | 1999 |
| control: | SIEMENS 840 C |
Technical Equipment/Features
| working area: |
| max. external work-piece diameter | 80 mm |
| max. nominal modul shapable | 5 mm |
| max. gearing width (straight gear) | 44 mm |
| adjustment of axis angle shaping spindle - workpiece table |
+0,5 bis +0,5° |
| stroke range | 250-1.500 DH/min |
| centre distance table/shaping spindle | -15 bis+170 mm |
| max. stroke length | 55 mm |
| max. helix angle | 45 Grad |
| max. tool diameter | 180 mm |
| feed range: | |
| feed rotation axis tool (relating to 100 mm work piece ∅) | 10 to 9.420 mm/min |
| feed rotation axis of work piece (reltating to 100 mm workpiece ∅) | 10 to 15.700 mm/min |
| feed center axis of machine column | 1 to 3.750 mm/min |
| dimensions, weight: |
| required space ca. | 4,2 x 2,6 x 2,6 m |
| machine weight ca. | 8.500 kg |
| electrical supply: | |
| total power consumption | 23 kVA |
| operating voltage | 400 V |
| operating frequency | 50 Hz |
| control voltage | 24 V DC |
| equipment |
- stroke positioning adjustment controlled by CNC
- stroke length adjustment mechanical-manually
- machine is fixed to the ground with specific damping shoes (part of the delivery scope)
- oil mist exhaust system
- tailstock
- shaping spindle and lift of shaping head equipped with hydrostatic bearing
